Automatically updates changed documents on drawing open.Uses named bookmarks, allows users to add text to linked range.Manage multiple document references easily.Override truetype fonts with a style name.Generates a layer report of the current drawing in an open document, including graphical icons.Įxports coordinates from nodal and linear geometry to a table in the document.Įxports table information from a table object to the currently open document. Simplifies the export of the current drawing to the currently open word document. Initiate the tools with your choice of the toolbar, ribbon or with the pull down menu. Word tables are placed inline as CAD table objects, including merged rows/columns. Narrow columns can often allow more information to fit on the sheet. You can set the page width to a narrow or wide value. The instance in the drawing doesn't have to be 8-1/2 inches wide. Let the clerical personnel use truetype fonts in the document, then use your favorite SHX font as an override in the drawing. A dozen page document can be plotted on an E size sheet with ease.īitmap images included in the document are placed in the resulting block. The text will flow to the designated height, then move up and to the right to continue. With Word2CAD's column wrapping, you can turn on this feature and specify the column height and gap distance. Long (multi-page) documents are not a problem. Recipients of your drawings on other CAD systems may have problems with the OLE representation.Ĭontrol the application with your choice of command line entry, pulldown menu, traditional toolbars or ribbon interface.OLE Objects can 'bleed through' multiple layouts, showing up in places where they don't belong.If the drawing is plotted rotated, the OLE does not.Plotting problems which OLE appears 'grainy', 'fuzzy', etc.OLE Size is limited to 'a single page'.OLE has it's limitations, Word2CAD doesn't So when you reopen your drawing, Word2CAD quickly evaluates the document instances in the drawing and automatically updates only those that have changed! Since the date and time of creation (along with the document file name) is stored, it can easily determine when the representation needs updating.
When Word2CAD creates the document the drawing, it stores extended data on the insert.
Automatically updates changed Word documents on drawing open.Also numerous refinements to existing tools and faster processing. New Release: We added support for Word Tables (even those including merged rows and columns) as well as inline images (bitmaps).
Bricscad v18 portable#
It draws the document using native geometry so the result is a bound collection of mtext (and table) objects that is linked to the original document, can be plotted without problems and is highly portable to other users. Word2CAD overcomes the limits and problems associated with OLE placement of Microsoft Word documents into AutoCAD, BricsCAD and IntelliCAD.
